Name: 3mm Diameter 45° Rod Mirror Aluminum Coated
Brand: TECHSPEC
SKU: 54-094
Price: NT$3,675

Length (mm):

6.00

Coating:

Protected Aluminum (400-700nm)

Angle Tolerance (arcmin):

±10

Bevel:

Protective bevel as needed

Coating Specification:

R_avg >85% @ 400 - 700nm

Coating Type:

Metal

Diameter (mm):

3.00 +0.00/-0.05

Length Tolerance (mm):

±0.1

Ray Deviation (°):

90.00

N-BK7

Surface Quality:

40-20

Type:

Rod Lens

Wavelength Range (nm):

400 - 700

Note:

Coating on Elliptical Surface

0.3 J/cm² @ 532nm & 1064nm, 10ns

Regulatory Compliance

RoHS 2015:

Compliant

Reach 219:

Compliant

Certificate of Conformance:

View

產品系列說明

備有鍍膜和無鍍膜產品
鍍膜產品可用於反射90°光線
無鍍膜產品可用於彎曲圖像路徑

TECHSPEC^® 45°柱狀反射鏡設計用於各種雷射和成像系統。這些反射鏡可用於彎曲圖像路徑，或將雷射光路轉折90°。因直徑較小，非常適用於對尺寸有嚴格要求的光纖鏡/內窺鏡應用。TECHSPEC^® 45°柱狀反射鏡具有經拋光的橢圓面、圓周和底面為磨砂面。這些元件有各種微小尺寸，可整合到大量 OEM 應用中。 
