    Broadband Laser Mirrors

    Broadband Laser Mirrors provide high reflectivity over a broad range of wavelengths, optimizing versatility for laser systems with multiple lasers, unusual wavelengths, or tunable laser sources. These mirrors are coated with either dielectric coatings covering most dye, diode, Ti:sapphire, Nd:YAG, and fiber laser sources or metallic coatings for applications requiring a more expansive reflectivity range. Broadband Laser Mirrors feature high surface quality and thermally-stable fused silica substrates, minimizing both scattering and thermal effects when used with lasers.

    Edmund Optics offers flat Broadband Laser Mirrors with angles of incidence from 0 o to 45o, as well as specialty options for applications from the UV to the IR. TECHSPEC Broadband Dielectric Laser Mirrors are available in UV, VIS, and NIR versions with >98% reflectivity at their design wavelength range. Broadband Dielectric Coated Right Angle Mirrors are offered with similar performance for easy mounting integration into laser systems. For Deep UV (DUV) and Vacuum UV (VUV) applications, Precision Ultraviolet Mirrors provide excellent reflection with aluminum-based coatings to minimize sensitivity to polarization. Knife-Edge Pickoff Mirrors coated with enhanced aluminum, protected gold, or protected silver are also available for separating closely propagating laser beams.

    寬頻電介質λ/10反射鏡
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    寬頻電介質λ/10反射鏡
    • 在廣波長範圍內的反射率超過99%
    • 專為入射角 0 - 45° 的所有偏振狀態設計
    • 採用熔融石英基材,具備優異的熱穩定性
    2μm 高色散寬頻超快雷射反射鏡 New
    ×

    2μm 高色散寬頻超快雷射反射鏡
    • 2000 - 2200nm 之間的反射率 >99.9%
    • 在 5 度 AOI 的 GDD 為 -1000fs2
    • 適用於脈衝壓縮 <100fs 的銩及鈥雷射
    • 寬頻超快啁啾式鍍膜
    1030nm 高色散寬頻超快反射鏡 New
    ×

    1030nm 高色散寬頻超快反射鏡
    • 在 5° 入射角達到 -200 fs2 的負 GDD
    • 在 950 - 1120nm 之間反射率高於 99.8%(P 偏振)
    • 設計用於摻鐿光纖雷射的脈衝壓縮
    • 寬頻超高速啁啾鍍膜
    45° AOI 超快啁啾反射鏡 New
    ×

    45° AOI 超快啁啾反射鏡
    • 高反射率及負群組延時色散 (GDD)
    • 適合在 45° AOI 提供色散補償及光束壓縮
    • 專為飛秒雷射所設計,包含摻鈦藍寶石雷射
    精密紫外線反射鏡
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    精密紫外線反射鏡
    • 120nm 及 190nm 設計波長
    • 在指定範圍內的平均反射率 >85%
    • 強化金屬鍍膜,提供寬頻反射率穿透可見光區域
    精密寬帶雷射反射鏡
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    精密寬帶雷射反射鏡
    • 特別適用於可調諧雷射及反射多個雷射光源
    • 針對所有偏振狀態,在0 - 45°範圍內具有高反射率
    • 提供多種鍍膜選項
    超快寬頻雷射光反射鏡
    超快寬頻雷射光反射鏡
    • >99% 反射率
    • 在 70-140nm 波長範圍提供高效能
    • 符合成本效益的解決方案 (<40 fs2 GDD @ CWL)
    • 也提供超快雷射光反射鏡
    刀緣傳感器反射鏡
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    New
    ×

    刀緣傳感器反射鏡
    • 小巧的 D 形半圓設計
    • 45° 斜邊
    • 多種鍍膜選項
    廣波段電介質鍍膜直角反射鏡
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More

    廣波段電介質鍍膜直角反射鏡

    ×
