Video Output:

USB 3.0

Type:

Monochrome Camera

Manufacturer:

Basler

Mounting Threads:

¼-20 with Tripod Mount Adapter #88-517

Image Buffer:

Not Specified

Camera Family:

ace

Model Number:

acA2440-35um

Imaging Sensor:

Sony IMX264

Type of Sensor:

Progressive Scan CMOS

Type of Shutter:

Global

Camera Sensor Format:

2/3"

Resolution (MegaPixels):

5.00

Pixels (H x V):

2,448 x 2,048

Pixel Size, H x V (μm):

3.45 x 3.45

Sensing Area, H x V (mm):

8.45 x 7.07

Frame Rate (fps):

35.00

Pixel Depth:

10/12 bit

Exposure Time:

Programmable via camera API, hardware trigger

Connector:

USB 3.0, Micro-B with Screw Locks

Power Supply:

Power over USB

Power Consumption (W):

2.5

GPIOs:

1 opto-coupled input line, 1 opto-coupled output line, 2 general purpose I/O (GPIO) lines

Synchronization:

Hardware Trigger (GPIO), Software Trigger, or Free-Run

Dimensions (mm):

29.3 x 29 x 29 (excludes connectors and lens mount)

Weight (g):

80

Mount:

C-Mount

Housing:

Full

Interface Port Orientation:

Back Panel

Dynamic Range (dB):

73.4

Operating Temperature (°C):

0 to +50

Storage Temperature (°C):

-20 to +80

GPIO Connector Type:

6-pin Hirose (HR10)

Machine Vision Standard:

USB3 Vision v1.0

Basler ace acA2440-35um Monochrome USB 3.0 Camera

Regulatory Compliance
